About the CAE Ultra Shifter Escort Cosworth MT75
CAE Ultra Shifter - Optimised for motor sports with the following features:
- CAE Ultra Shifter for Ford Escort Cosworth with standard MT75 gearbox (not suitable for Borg warner and Quaife Big Tooth gearbox).
- Short and super-precise shifting travel, exclusively H-pattern
- The coupling system remains in its original form.
- Characterised by its optimal ergonomics with a focus on motor sports: perfect positioning of the shift lever close to the steering wheel. The shift pattern is confined to approx. 65 x 65 mm.
- Low weight and high stability: the milled and lathed parts consist of 7075 aluminium alloy; the substructures are made out of laser-cut, 3 mm thick AlMg3 aluminium. The parts are combined in the WIG welding process and brushed blank for an optimal finish.
- easy shifting of gears under stress or in curves.
- Integrated centre position spring, ensuring perfect feedback when changing columns while shifting up and down.
- Right/left stops adjustable separately.
- Shifter will be delivered as complete kit including CAE adjustable shift rod milled from 7075 aluminium,
- centre console has to be modified
Surface of the shifter and shift knob selectable in different versions, optional against extra charge wrapped with grey alcantara with colored X-seam
This shifter has no reverse gear lock.
| Total height: | approx. 400 mm |
| Total length: | approx. 180 mm |
| Dimensions of base plate: | approx. 150 x 125 mm |
| Shifting travel: | approx. 65 mm |
| Selector travel (transverse direction): | approx. 65 mm |
| Weight (complete): | approx. 1,05 kg |
| Offset of the gear lever knop (back / up): | approx. 50 / 170 mm |
technical data
| Item information | Value |
|---|---|
| Transmission: | MT75 |
| CAE Shifter Type: | H-Pattern shifted |
| Brand: | Ford |
| Car-Model: | Escort Cosworth |
| Item weight: | 2 kg |
scope of supply
1x CAE Ultra Shifter Escort Cosworth MT75 , Scope of delivery as shown.
