About the CAE Shifter AUDI STREET Type B4/5/6 anod. black
(not for use with OEM shift knob)
Designed for motorsport but almost invisible
This shifter allows you to keep all the trim parts of the center console (light machining required for type B4)
- CAE Ultra Shifter for all Áudi 80-90 ff Typ B4/5/6 with a Audi 01E Rod-Gearbox ; Modification to cable shift
- Short and super-precise shifting travel, exclusively H-pattern.
- The clutch system remains in its original form.
- Characterised by its optimal ergonomics with a focus on motor sports: perfect positioning of the shift lever closer to the steering wheel. The shift pattern is confined to approx. 75 x 75 mm.
- Activation of the reverse gear lock via cable reel from the shift lever. An accidental changing to the reverse gear is impossible. The reverse gear is unlocked by pulling up the sliding collar on the shift lever.
- Low weight and high stability: the milled and lathed parts consist of high strength Aicraft aluminium; the substructures are made out of laser-cut, 3 mm thick AlMg3 aluminium.
- Problem-free shifting of gears under stress or in curves.
- Integrated centre position spring, ensuring perfect feedback when changing columns while shifting up and down.
- Right/left stops and reverse gear stop adjustable separately.
- Shifter is mounted on the center tunnel and is intended for vehicles without interior equipment or without a centre console and make use of the mounting points of the original shift lever.
shift knob selectable in different versions, optional against extra charge wrapped with grey alcantara with colored X-seam
| Total height: | approx. 320 mm |
| Total length: | approx. 250 mm |
| Dimensions of base plate: | similar to stock |
| Shifting travel: | approx. 75 mm |
| Selector travel (transverse direction): | approx. 75 mm |
| Weight (complete): | approx. 3,7 kg |
| Offset of the gear lever knop (back / up): | approx. 20 / 70 mm |
technical data
| Item information | Value |
|---|---|
| Transmission: | 01E 5 & 6 Speed |
| CAE Shifter Type: | H-Pattern shifted |
| Item weight: | 3 kg |
scope of supply
1x CAE Shifter AUDI STREET Type B4/5/6 anod. black , Scope of delivery as shown.
